138 Functional Description Emotron AB 01-3694-01r2
PT100_1_2_3 Temp [71B]
Displays the actual PT100 temperature.
Communication information
11.8.2 Status [720]
VSD Status [721]
Indicates the overall status of the variable speed drive.
Fig. 110 VSD status
Example: “A/Key/Rem/TL”
This means:
A: Parameter Set A is active.
Key: Reference value comes from the keyboard (CP).
Rem: Run/Stop commands come from terminals 1-22.
TL: Torque Limit active.
Warning [722]
Display the actual or last warning condition. A warning
occurs if the VSD is close to a trip condition but still in
operation. During a warning condition the red trip LED
will start to blink as long as the warning is active.
The active warning message is displayed in menu [722].
If no warning is active the message “No Warning” is dis-
played.
The following warnings are possible:
Unit: °C
Resolution: 1°C
Modbus Instance no/DeviceNet no: 31012, 31013, 31014
Profibus slot/index 121/156
Fieldbus format Long
Modbus format EInt
Display
position
Status Value
1 Parameter Set A,B,C,D
222
Source of reference
value
-Key (keyboard)
-Rem (remote)
-Com (Serial comm.)
-Opt (option)
333
Source of Run/
Stop/Reset com-
mand
-Key (keyboard)
-Rem (remote)
-Com (Serial comm.)
-Opt (option)
44 Limit functions
-TL (Torque Limit)
-FL (Frequency Limit)
-CL (Current Limit)
-VL (Voltage Limit)
- - - -No limit active
71B PT100 1,2,3
Stp °C
721 VSD Status
Stp 1/222/333/44
Selection Warning message
0No Error
1Motor I²t
2PTC
3Motor lost
4Locked rotor
5 Ext trip
6Mon MaxAlarm
7Mon MinAlarm
8 Comm error
9PT100
11 Pump
12 Not used
13 Not used
14 Not used
15 Option
16 Over temp
17 Over curr F
18 Over volt D
19 Over volt G
20 Over volt M
21 Over speed
22 Under voltage
23 Power fault
24 Desat
25 DClink error
26 Int error
27 Ovolt m cut
28 Over voltage
29 Warning 30
722 Warnings
Stp warn.msg
