Emotron AB 01-3694-01r2 Functional Description 73
Motor Class [235]
Only visible if the PTC/PT100 option board is installed. Set
the class of motor used. The trip levels for the PT100 sensor
will automatically be set according to the setting in this
menu.
Communication information
PT100 Inputs [236]
Sets which of PT100 inputs that should be used for thermal
protection. Deselecting not used PT100 inputs on the PTC/
PT100 option board in order to ignore those inputs, i.e.
extra external wiring is not needed if port is not used.
Communication information
11.3.5 Parameter Set Handling [240]
There are four different parameter sets available in the VSD.
These parameter sets can be used to set the VSD up for dif-
ferent processes or applications such as different motors used
and connected, activated PID controller, different ramp
time settings, etc.
A parameter set consists of all parameters with the exception
of the menu [211] Language, [217] Local Remote, [218]
Lock Code, [220] Motor Data, [241] Select Set and [260]
Serial Communication.
Select Set [241]
Here you select the parameter set. Every menu included in
the parameter sets is designated A, B, C or D depending on
the active parameter set. Parameter sets can be selected from
the keyboard, via the programmable digital inputs or via
serial communication. Parameter sets can be changed during
the run. If the sets are using different motors (M1 to M4)
the set will be changed when the motor is stopped.
Default: F 140°C
A 100
°C0
E 115
°C1
B 120
°C2
F 140
°C3
F Nema
145
°C
4
H 165
°C5
Modbus Instance no/DeviceNet no: 43065
Profibus slot/index 168/224
Fieldbus format UInt
Modbus format UInt
NOTE: This menu is only valid for PT 100.
Default: PT100 1+2+3
Selection:
PT100 1, PT100 2, PT100 1+2, PT100
3, PT100 1+3, PT100 2+3, PT100
1+2+3
PT100 1 1 Channel 1 used for PT100 protection
PT100 2 2 Channel 2 used for PT100 protection
PT100 1+2 3 Channel 1+2 used for PT100 protection
PT100 3 4 Channel 3 used for PT100 protection
PT100 1+3 5 Channel 1+3 used for PT100 protection
PT100 2+3 6 Channel 2+3 used for PT100 protection
PT100 1+2+3 7
Channel 1+2+3 used for PT100 protec-
tion
235 Mot Class
Stp F 140°C
A
236 PT100 Inputs
Stp PT100 1+2+3
A
Modbus Instance no/DeviceNet no: 43066
Profibus slot/index 168/225
Fieldbus format UInt
Modbus format UInt
NOTE: This menu is only valid for PT 100 thermal
protection.
NOTE: Actual timers are common for all sets. When a set
is changed the timer functionality will change according
to the new set, but the timer value will stay unchanged.
Default: A
Selection: A, B, C, D, DigIn, Com, Option
A0
Fixed selection of one of the 4 parameter
sets A, B, C or D.
B1
C2
D3
DigIn 4
Parameter set is selected via a digital
input. Define which digital input in menu
[520], Digital inputs.
Com 5
Parameter set is selected via serial com-
munication.
Option 6
The parameter set is set via an option.
Only available if the option can control the
selection.
241 Select Set
Stp A
A
