74 Functional Description Emotron AB 01-3694-01r2
Communication information
The active set can be viewed with function [721] FI status.
Copy Set [242]
This function copies the content of a parameter set into
another parameter set.
Communication information
A>B means that the content of parameter set A is copied
into parameter set B.
Load Default Values Into Set [243]
With this function three different levels (factory settings)
can be selected for the four parameter sets. When loading
the default settings, all changes made in the software are set
to factory settings. This function also includes selections for
loading default settings to the four different Motor Data
Sets.
Communication information
Copy All Settings to Control Panel [244]
All the settings can be copied into the control panel includ-
ing the motor data.
Modbus Instance no/DeviceNet no: 43022
Profibus slot/index 168/181
Fieldbus format UInt
Modbus format UInt
NOTE: Parameter set cannot be changed during run if
this also would imply a change of the motor set (M2-
M4).
Default: A>B
A>B 0 Copy set A to set B
A>C 1 Copy set A to set C
A>D 2 Copy set A to set D
B>A 3 Copy set B to set A
B>C 4 Copy set B to set C
B>D 5 Copy set B to set D
C>A 6 Copy set C to set A
C>B 7 Copy set C to set B
C>D 8 Copy set C to set D
D>A 9 Copy set D to set A
D>B 10 Copy set D to set B
D>C 11 Copy set D to set C
Modbus Instance no/DeviceNet no: 43021
Profibus slot/index 168/180
Fieldbus format UInt
Modbus format UInt
242 Copy Set
Stp A
>B
A
Default: A
A0
Only the selected parameter set will revert
to its default settings.
B1
C2
D3
ABCD 4
All four parameter sets will revert to the
default settings.
Factory 5
All settings, except 211, 261, 3A1 and
923, will revert to the default settings.
M1 6
Only the selected motor set will revert to its
default settings.
M2 7
M3 8
M4 9
M1234 10
All four motor sets will revert to default set-
tnings.
Modbus Instance no/DeviceNet no: 43023
Profibus slot/index 168/182
Fieldbus format UInt
Modbus format UInt
NOTE: Trip log hour counter and other VIEW ONLY menus
are not regarded as settings and will be unaffected.
NOTE: If “Factory” is selected, the message “Sure?” is
displayed. Press the + key to display “Yes” and then
Enter to confirm.
NOTE: The parameters in menu [230], Motor data, are
not affected by loading defaults.
Default: No Copy
No Copy 0 Nothing will be copied
Copy 1 Copy all settings
243 Default>Set
Stp A
A
244 Copy to CP
Stp No Copy
A
