Emotron AB 01-3694-01r2 Technical Data 161
14.5 Dimensions and Weights
The table below gives an overview of the dimensions and
weights. The models 300 to 1500 consist of 2 or 3 parallel-
led drive modules built into a standard cabinet
14.6 Environmental conditions
Table 40 Mechanical specifications
Models
Frame
size
Dim. H x W x D [mm]
IP20
Dim. H x W x D [mm]
IP54
Weight IP20
[kg]
Weight IP54
[kg]
003 to 013 X1 350(400)x 220 x 150 350(400)x 220 x 150 10 10
018 to 037 S2 – 470(530) x 176 x 272 – 19
046 to 073 X2 530(590) x 220 x 270 530(590) x 220 x 270 26 26
90 to 109 E – 950 x 285 x 314 – 56
146 to 175 E – 950 x 285 x 314 – 60
210 to 250 F – 950 x 345 x 314 – 74
300 to 375 G 1036 x 500 x 390 2320 x 600 x 500 140 270
430 to 500 H 1036 x 500 x 450 2320 x 600 x 600 170 305
600 to 750 I 1036 x 730 x 450 2320 x 1000 x 600 248 440
860 to 1000 J 1036 x 1100 x 450 2320 x 1200 x 600 340 580
1200 to 1500 K 1036 x 1560 x 450 2320 x 2000 x 600 496 860
Table 41 Operation
Parameter Normal operation
Nominal ambient temperature 0°C–40°C See table, see Table 38 for different conditions
Atmospheric pressure 86–106 kPa
Relative humidity, non-condensing 0–90%
Contamination,
according to IEC 60721-3-3
No electrically conductive dust allowed
Cooling air must be clean and free from corrosive materials
Chemical gases, class 3C2
Solid particles, class 3S2
Vibrations
According to IEC 600068-2-6
Sinusodial vibrations:
•10<f<57 Hz, 0.075 mm
•57<f<150 Hz, 1g
Altitude 0–1000 m, with derating of output up to 2000 m.
Table 42 Storage
Parameter Storage condition
Temperature -20 to +60 °C
Atmospheric pressure 86–106 kPa
Relative humidity, non-condensing 0– 90%
