Emotron AB 01-3694-01r2 Functional Description 119
Communication information
Digital Input 2 [522] to Digital Input 8
[528]
Same function as DigIn 1 [521]. Default function for DigIn
8 it is Reset. For DigIn 3 to 7 the default function is Off.
Communication information
Additional digital inputs [529] to [52H]
Additional digital inputs with I/O option board installed,
B1 DigIn 1 [529] - B3 DigIn 3 [52H]. B stands for board
and 1 to 3 stand for the number of the board. The functions
and selections are the same as DigIn 1 [521].
Communication information
11.6.3 Analogue Outputs [530]
Submenu with all settings for the analogue outputs. Selec-
tions can be made from application and VSD values, in
order to visualize actual status. Analogue outputs can also be
used as a mirror of the analogue input. Such a signal can be
used as:
• a reference signal for the next VSD in a Master/Slave
configuration (see Fig. 103).
• a feedback acknowledgement of the received analogue
reference value.
AnOut1 Function [531]
Sets the function for the Analogue Output 1. Scale and
range are defined by AnOut1 Advanced settings [533].
Jog 26
To activate the Jog function. Gives a Run
command with the set Jog speed and
Direction, page 94.
Ext Mot
Temp
27
Be aware that if there is nothing con-
nected to the input, the VSD will trip at
“External Motor Temp” immediately.
NOTE: The External Motor Temp is active
low.
NOTE: For bipol function, input RunR and RunL needs to
be active and Rotation, [219] must be set to “R+L”.
Modbus Instance no/DeviceNet no: 43241
Profibus slot/index 169/145
Fieldbus format UInt
Modbus format UInt
Ta b le 2 5
Parameter Set Set Ctrl 1 Set Ctrl 2
A00
B10
C01
D11
NOTE: To activate the parameter set selection, menu
241 must be set to DigIn.
Default: RunR
Selection: Same as in menu
[521]
Modbus Instance no/DeviceNet no: 43241–43248
Profibus slot/index 169/146–169/152
Fieldbus format UInt
Modbus format UInt
522 DigIn 2
Stp RunR
A
Modbus Instance no/DeviceNet no: 43501–43509
Profibus slot/index 170/150–170/158
Fieldbus format Int
Modbus format Int
Default: Speed
Process Val 0
Actual process value according to Proc-
ess feedback signal.
Speed 1 Actual speed.
Torque 2 Actual torque.
Process Ref 3 Actual process reference value.
Shaft Power 4 Actual shaft power.
Frequency 5 Actual frequency.
Current 6 Actual current.
El power 7 Actual electrical power.
Output volt 8 Actual output voltage.
DC-voltage 9 Actual DC link voltage.
AnIn1 10 Mirror of received signal value on AnIn1.
AnIn2 11 Mirror of received signal value on AnIn2.
AnIn3 12 Mirror of received signal value on AnIn3.
AnIn4 13 Mirror of received signal value on AnIn4.
531 AnOut1 Fc
Stp Speed
A
