Fig. 122
13.10 Crane option board
This option is used in crane applications. The crane option
board 2.0 is described in a separate manual.
13.11Encoder
The Encoder 2.0 option board, used for connection of feed-
back signal of the actual motor speed via an incremental
encoder is described in a separate manual.
13.12PTC/PT100
The PTC/PT100 2.0 option board for connecting motor
thermistors to the VSD is described in a separate manual.
=
~
=
X1
1
2
3
4
5
6
U
V
W
10
20
X1
Safe Stop
+5V
+24 VDC
K1
K2
Power board
PWMController
DigIn
DigOut
Enable
Stop
