14.7 Fuses, cable cross-
sections and glands
Use mains fuses of the type gL/gG conforming to IEC 269
or installation cut-outs with similar characteristics. Check
the equipment first before installing the glands.
Max. Fuse = maximum fuse value that still protects the VSD
and upholds warranty.
NOTE: The dimensions of fuse and cable cross-section
are dependent on the application and must be
determined in accordance with local regulations.
NOTE: The dimensions of the power terminals used in the
models 300 to 1500 can differ depending on customer
specification.
Table 43 Fuses, cable cross-sections and glands
Model
Nominal
input current
[A]
Maximum
value fuse
[A]
Maximum cable cross-
section
connector [mm
2
]
Clamping range glands [mm]
Frame
size
Mains Motor Mains Motor
FDU40-003
FDU40-004
FDU40-006
FDU40-008
FDU40-010
FDU40-013
2
3
5
6
8
11
6
6
10
10
16
16
6 6 M20 (7–13) M20 (8.5–13) X1
FDU**-018
FDU**-026
FDU**-031
FDU**-037
11
16
22
26
31
16
20
25
35
35
16 16 Ø32 (cable entry) Ø32 (cable entry) S2
FDU**-046
FDU**-060
FDU**-073
38
51
64
50
63
80
16
25
50
16
25
50
M40 (19 - 28) M40 (27 - 34) X2
FDU**-090
FDU**-109
FDU**-146
FDU**-175
78
94
126
152
100
100
160
160
35–150 35–150
Ø30–45 cable
entry or
M63 (34–45)
Ø30–45 cable
entry or
M63 (34–45)
E
FDU**-210
FDU**-250
182
216
200
250
35–240 35–240
Ø27–66 cable
entry
Ø27–66 cable
entry
F
FDU**-300
FDU**-375
260
324
315
355
(2x) 35–240 (2x) 35–150 - - G
FDU**-430
FDU**-500
372
432
400
500
(2x) 35–240 (2x) 35–240 - - H
FDU**-600
FDU**-650
FDU**-750
520
562
648
630
630
710
(3x) 35–240 (3x) 35–240 - - I
FDU**-860
FDU**-1000
744
864
800
1000
(4x) 35–240 (4x) 35–240 - - J
FDU**-1200
FDU**-1500
1037
1296
1250
1500
(6x) 35–240 (6x) 35–240 - - K
