136 Functional Description Emotron AB 01-3694-01r2
Communication information
Timer 2 Value [659]
Timer 2 Value shows actual value of the timer..
Communication information
11.8 View Operation/Status
[700]
Menu with parameters for viewing all actual operational
data, such as speed, torque, power, etc.
11.8.1 Operation [710]
Process Value [711]
The process value is a display function which can be pro-
grammed according to several quantities and units related to
the reference value.
Communication information
Speed [712]
Displays the actual shaft speed.
Communication information
Torque [713]
Displays the actual shaft torque.
Communication information
Shaft power [714]
Displays the actual shaft power.
Communication information
Modbus Instance no/DeviceNet no:
43459 hours
43460 minutes
43461 seconds
Profibus slot/index
170/108, 170/109,
170/110
Fieldbus format UInt
Modbus format UInt
Default: 0:00:00, hr:min:sec
Range: 0:00:01–9:59:59
Modbus Instance no/DeviceNet no:
42924 hours
42925 minutes
42926 seconds
Profibus slot/index
168/83, 168/84,
168/84
Fieldbus format UInt
Modbus format UInt
Modbus Instance no/DeviceNet no: 31001
Profibus slot/index 121/145
Fieldbus format Long, 1=0.001
Modbus format EInt
659 Timer2 Value
Stp 0:00:00
A
711 Process Val
Stp
Unit: rpm
Resolution: 1 rpm, 4 digits
Modbus Instance no/DeviceNet no: 31002
Profibus slot/index 121/146
Fieldbus format Int, 1=1 rpm
Modbus format Int, 1=1 rpm
Unit: Nm
Resolution: 1 Nm
Modbus Instance no/DeviceNet no:
31003 Nm
31004%
Profibus slot/index 121/147
Fieldbus format Long, 1=1%
Modbus format EInt
Unit: W
Resolution: 1W
Modbus Instance no/DeviceNet no: 31005
Profibus slot/index 121/149
Fieldbus format Long, 1=1W
Modbus format EInt
712 Speed
Stp rpm
713 Torque
Stp 0% 0.0Nm
714 Shaft Power
Stp W
