144 Functional Description Emotron AB 01-3694-01r2
Communication information
V 4.03 = Version of the Software
Unit name [923]
Option to enter a name of the unit for service use or cus-
tomer identity. The function enables the user to define a
name with 12 symbols. Use the Prev and Next key to move
the cursor to the required position. Then use the + and -
keys to scroll in the character list. Confirm the character by
moving the cursor to the next position by pressing the Next
key. See section User-defined Unit [323].
Example
Create user name USER 15.
1. When in the menu [923] press Next to move the cursor
to the right most position.
2. Press the + key until the character U is displayed.
3. Press Next.
4. Then press the + key until S is displayed and confirm
with Next.
5. Repeat until you have entered USER15.
Communication information
When sending a unit name you send one character at a time
starting at the right most position.
Modbus Instance no/DeviceNet no:
31038 software version
31039 option version
Profibus slot/index 121/182
Fieldbus format UInt
Modbus format UInt
Table 27 Information for Modbus and Profibus number
Bit Description
7–0 minor
8–13 major
14–15 release
0V, release version
1 P, pre-release version
2 β, Beta version
3
α, Alpha version
NOTE: It is important that the software version displayed
in menu [920] is the same software version number as
the software version number written on the title page of
this instruction manual. If not, the functionality as
described in this manual may differ from the
functionality of the VSD.
Default: No characters shown
Modbus Instance no/DeviceNet no:
42301
42302
42303
42304
42305
42306
42307
42308
42309
42310
42311
42312
Profibus slot/index
165/225
165/226
165/227
165/228
165/229
165/230
165/231
165/232
165/233
165/234
165/235
165/236
Fieldbus format UInt
Modbus format UInt
923 Unit Name
