Emotron VFX 2.0 User Manual

108 Functional Description Emotron AB 01-4429-01r2
Max Alarm [416]
Max Alarm Margin [4161]
With load type Basic, [415], used the Max Alarm Margin
sets the band above the Normal Load, [41B], menu that
does not generate an alarm. With load type Load Curve,
[415], used the Max Alarm Margin sets the band above the
Load Curve, [41C], that does not generate an alarm. The
Max Alarm Margin is a percentage of nominal motor
torque.
Communication information
Max Alarm delay [4162]
Sets the delay time between the first occurrence of max
alarm condition and after when the alarm is given.
Communication information
Max Pre Alarm [417]
Max Pre AlarmMargin [4171]
With load type Basic, [415], used the Max Pre-Alarm Mar-
gin sets the band above the Normal Load, [41B], menu that
does not generate a pre-alarm. With load type Load Curve,
[415], used the Max Pre-Alarm Margin sets the band above
the Load Curve, [41C], that does not generate a pre-alarm.
The Max Pre-Alarm Margin is a percentage of nominal
motor torque.
Communication information
Max Pre Alarm delay [4172]
Sets the delay time between the first occurrence of max pre
alarm condition and after when the alarm is given.
Communication information
Min Pre Alarm [418]
Min Pre Alarm Margin [4181]
With load type Basic, [415], used the Min Pre-Alarm Mar-
gin sets the band under the Normal Load, [41B], menu that
does not generate a pre-alarm. With load type Load Curve,
[415], used the Min Pre-Alarm Margin sets the band under
the Load Curve, [41C], that does not generate a pre-alarm.
The Min Pre-Alarm Margin is a percentage of nominal
motor torque.
Default: 15%
Range: 0–400%
Modbus Instance no/DeviceNet no: 43326
Profibus slot/index 169/230
Fieldbus format Long, 1=1%
Modbus format EInt
Default: 0.1 s
Range: 0-90 s
Modbus Instance no/DeviceNet no: 43330
Profibus slot/index 169/234
Fieldbus format Long, 1=0.1 s
Modbus format EInt
4161 MaxAlarmMar
Stp 15%
A
4162 MaxAlarmDel
Stp 0.1s
A
Default: 10%
Range: 0–400%
Modbus Instance no/DeviceNet no: 43327
Profibus slot/index 169/231
Fieldbus format Long, 1=0.1%
Modbus format EInt
Default: 0.1 s
Range: 0–90 s
Modbus Instance no/DeviceNet no: 43331
Profibus slot/index 169/235
Fieldbus format Long, 1=0.1 s
Modbus format EInt
Default: 10%
Range: 0-400%
4171 MaxPreAlMar
Stp 10%
A
4172 MaxPreAlDel
Stp 0.1s
A
4181 MinPreAlMar
Stp 10%
A
