Addendum
Emotron AB, Mörsaregatan 12, SE-250 24 Helsingborg, Tel: +46 42 16 99 00, Fax: +46 42 16 99 49
www.emotron.com
Emotron AB 01-4934-01r1 2009-10-30
14. Technical Data
14.1 Electrical specifications related
to model
New models for VFX2.0 and FDU2.0 with 480V rated
voltage. The 228 Amp unit is the largest unit in frame size F
available with UL approval
* Available during limited time and as long as allowed by
drive temperature.
Model
Max.
output
current
[A] *
Normal duty
(120%, 1 min every 10 min)
Heavy duty
(150%, 1 min every 10 min)
Frame size
Power@
400 V
[kW]
Power@
460 V
[hp]
Rated
current
[A]
Power@
400 V
[kW]
Power@
460 V
[hp]
Rated
current
[A]
FDU/VFX 48-228 300 110 200 228 90 150 182 F
