Removing an interface card
Follow these steps to remove an optional interface card.
c
Caution:
Before you remove an interface card, be sure to discharge any
static electricity by touching a grounded piece of metal.
Otherwise, you may damage static-sensitive components.
1. Loosen and remove thetwoscrews securing the interface card
onto the back of the printer.
2. Gently but firmly pull the interface card out until it is released
from the printer’s internal socket.
3. Replace the interface slot cover (removed and stored when
the interface card was installed) over the now empty slot. Use
the two screws to secure it.
4. Keep the interface card in an anti-static packet such as the one
it came packaged in.
Printing a Status Sheet
To confirm that the options are installed correctly, print a status
sheet using the printer's control panel.
1. Turn on the printer. After about 30 seconds, the LCD panel
shows
Ready
.
