Epson LX-300 Service Manual

LX-300 Service Manual
Prvduct Description
Table 1-8. Specifications for Continuous Paper with a Label
Label size (W x L)
63.5 mm (min.) x 23.8 mm (min.) [ 2.5 in. (min.)
x 15/16 in. (min.)]
Width of base paper
101.6 mm -254 mm (4.0 in. x 10.0 in.)
Thickness of base
paper
0.07 mm - 0.09 mm (0.0028 in. - 0.0035 in.)
Total thickness
0.16 mm - 0.19 mm (0.0063 in. -0.0075 in.)
I
Weight
64g/m2(17 lb.)
Quality
Plain paper
Notes:
● Use only continuous-type labels and use them only with the tractor.
● Example of labels
— Avery Continuous Form Labels
— Avery Mini-Line Labels
● Printing of envelopes is guaranteed only when the temperature is room temperature
and humidity is normal (15 - 25° C (59 - 77° F), 20- 6(YXO RI-l).
Table 1-9. Roll Paper Specifications
Width 213 mm -219 mm (8.38 in. -8.62 in.)
I
Diameter 127 mm (5.0 in.)
Thickness 0.070 mm -0.090 mm (0.0028 in. - 0.0035 in.)
Weiaht
I 52- 64a/m2 (14 -17 lb.)
1.2.1.3 Printable Area
Cut shaets using manual insartion
3 mm
[0 1%], nym.m
3 mm
[0.12’]. Ilirimbm
\
. . . . . . . . . . . . ,.. - . . ,
Printable Area
209.2 mm 10~. MEximum
—
F
BC
7
XYz
L
BC
—
-J
)wz
—
Figure 1-3. Printable Area for Cut Sheets Using
Manual Insertion
Rev. A
1-s

Epson LX-300 Specifications

General

Print Method	9-pin impact dot matrix
Interface	Parallel
Paper Handling	Friction feed, tractor feed
Weight	4.4 kg
Operating Environment	Temperature: 5 - 35°C, Humidity: 10 - 80%
