Disassembly and Assembly
LXi300
Service
M5nual
3.2.6 Removing the ROLLER ASSY.,DRIVEN
1.
Remove the
COVER,PRINTER.
2. Remove the
CF
(M2.6 x 8) screw attaching the ROLLER
ASSY.,DRTVEN.
3. Remove the ROLLER
ASSY.,DRIVEN.
CF(M2.6X8)
ROLLER, DRIVEN
I
SPRING,73
.h
/A
&
/
0
W~DE;R,ROLLER,
COVER, ROLLER, DRIVEN
!’
,’
“’
i
“T.e
COVER, PRINTER
\v
Figure 3-19. Removing the ROLLER ASSY.,DRIVEN
3-18
Rev.A
