Epson LX-300 Service Manual

LX-300 Service Manual
Product Daadption
1.1 FEATURES
The LX-300 is a small, light-weight, 9-pin serial impact dot-matrix color printer suitable for
personal use. The major features of this printer areas follows:
0 Fast printing of 10-cpi draft characters at 220 cps
Cl Compact design saves precious workspace
Cl Easy-to-operate panel
LI Quiet printing
CI Standard 8-bit parallel interface and EIA-232D serial interface
D Printing of up to 66 lines on A4-size or 62 lines on letter-size paper
~ Optional color printing usinga color ribbon (black, magenta, cyan, yellow)
~ Detachable push and pull tractor
Figure 1-1 shows an exterior view of the LX-300 and Table 1-1 lists the optional units available for
the LX-300.
Edge guties ~
~p”perwppof’s
A
Power
lease
YA&
r
feed
b
.. ./,
/’= A%
w
Pfintercover #/< A
5
Print head
Sprocket unit
Paper Jpport
Troctof
-
Figure 1-1. Exterior”View of the LX-300
Table 1-1. Optional Units
I
Model
Description
I
#8750
Ribbon cartridge (monochrome)
#8758
Ribbon cartridge (monochrome, sub-mtridge)
,
I
S015073
I Ribbon cartridge (color)
I
C80837* Single-bin cut sheet feeder
C83208*
Color upgrade kit
I C80030* [ Pulitractorunit
I
I
#8310
I Roil paper holder
I
Rev. A 1-1

Epson LX-300 Specifications

General

Print Method	9-pin impact dot matrix
Interface	Parallel
Paper Handling	Friction feed, tractor feed
Weight	4.4 kg
Operating Environment	Temperature: 5 - 35°C, Humidity: 10 - 80%
