LX-300 Service Manual
Operating Pdncipb
Fulcrum
Color Ribbon Cartridge
1/
LEVER,CS
-—-
-
HOLDER, CARTRIDGE,COLOR
Pinion of MOTOR
ASSY.,CS
Color Shift Cam
Color Shift Cam Follower
Figure 2-9. Color Shift Mechanism
2.1.6 Platen Gap Adjustment Mechanism
‘The platen gap (the gap between the platen and the printhead) can
be
adjusted to allow the printer
to use paper of different weights or thicknesses. When the gap adjust lever is moved forward or
backward, the CR guide shaft rotates. This rotation moves the carriage either toward or away from
the platen and changes the platen gap. The correct platen gap is 0.45
tO.02
mm with the gap adjust
lever set to position O.
LEVER,G,ADJUST Motion
PG
II
1
\
,LEVER’GJADJUST
,
i’1
.*pfinthead
TL
,,
,
i$-
“>
printhad
Motion”
F
“-””l
5
a
.
.
.
.“
Platen
\
SHAFT,CR,GUIDE
Figure 2-10. Platen Gap Adjustment Mechanism
Rev.A
2-9
