Epson LX-300 Service Manual

CHAPTER 4 Adjustments
Table of Contents
4.1 ADJUSTING THE PRINTER MECHANISM
4-1
4.1.1 Platen Gap Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.2 DEFAULTS, MACHINE INFORMATION
S~lNGS, AND
BIDIRECTIONAL ADJUSTMENT
4-2
4.2.1 Default Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.2.2 Bidirectional Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
List of Figures
Figure 4-1. The Flowchart of the Platen Gap Adjustment . . . . . . . . . . . . . . . . . 4-1
Figure 4-2. The Bidirectional Pattern Print. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4

Epson LX-300 Specifications

General

Print Method	9-pin impact dot matrix
Interface	Parallel
Paper Handling	Friction feed, tractor feed
Weight	4.4 kg
Operating Environment	Temperature: 5 - 35°C, Humidity: 10 - 80%
