LX-300+/1170 Revision C
PRODUCT DESCRIPTION
ontrol codes 34
*4 m2 and m3 apply to the following ID number. (See Table 1-24 & Table 1-25.)
*5 m1=0 to 7 only
<Remote commands>
Table 1-23. Note for Table 1-22
m1 set by AT/CT m2 set by AT m3 set by AT
0 0 0
1 All parameters that can be set
Table 1-24. Std and NLSP ver.
m2 m3 Character table m2 m3 Character table
00H 00H Italic 19H 00H BRASCII
01H 00H PC437 1AH 00H Abicomp
03H 00H PC850 7FH 01H ISO Latin1
07H 00H PC860 23H 00H Roman8
08H 00H PC863 2CH 00H PC858
09H 00H PC865 1DH 0FH ISO 8859-15
18H 00H PC861
Table 1-25. NLSP ver. only
m2 m3 Character table m2 m3 Character table
01H 10H PC437 Greek 1CH 00H Code MJK
05H 00H PC853 1DH 07H ISO 8859-7
06H 00H PC855 1FH 00H ISO Latin 1T
0AH 00H PC852 20H 00H Bulgaria
0BH 00H PC857 21H 00H Hebrew 7
0CH 00H PC862 22H 00H Hebrew 8
0DH 00H PC864 24H 00H PC 774
0EH 00H PC866 25H 00H Estonia
0EH 20H PC866 LAT. 28H 00H PC APTEC
0EH 30H PC866 UKR 29H 00H PC 708
0FH 00H PC869 2AH 00H PC720
0DH 20H PCAR_864 7FH 02H ISO 8859-2
1BH 00H MAZOWIA 2DH 00H PC771
Table 1-26. Bi-Directional Commands
Function Code/ Parameter Save
Set page length “PG” 05H 00H 00H p1 p2 m1 m2
p1=0(Continuous paper), p2=0(Rear),
p1=1(CSF), p2=0(bin1)
p1=2(Manual insertion), p2=0(rear)
-Page legth=m1+256*m2,
0.118mm (1/216inch)
648 (76.2mm(3inch)) <= m1+256*m2 <=
4752(558.8mm(22 inch))
¡
Set Top margin “TP” 05H 00H 00H p1 p1 m1 m2
p1=0(Continuous paper), p2=0(Rear),
p1=1(CSF), p2=0(bin1)
p1=2(Manual insertion), p2=0(rear)
-Top margin=m1+256*m2,
0.118mm (1/216inch)
36 (4.2mm) <= m1+256*m2 <= 288 (8.5mm +
25.4mm(1inch))
¡
Turn unidirectional mode on/
off
“PD” 02H 00H 00H m1
m1=0(Bi-d.), 1(Uni-d.)
¡
Turn auto tear-off on/off “TO” 02H 00H 00H m1
m1=0(off), 1(on)
¡
Turn auto line feed on/off “LF” 02H 00H 00H m1
m1=0(off), 1(on)
¡
Table 1-25. NLSP ver. only
m2 m3 Character table m2 m3 Character table
