Using Your Printer with DOS
5-8
2. Load several sheets of paper at least 8.3 inches (210 mm)
wide in the built-in sheet feeder, making sure the right edge
guide is positioned correctly for your paper’s width. Also
make sure the paper release lever is set to the single sheet
position. (See page 3-6 for instructions.)
3. Insert the
EPSON printer software CD-ROM or diskette
into a drive.
4. At the DOS prompt, type
d
:\SETUP (where
d
is the drive
letter of your drive) and press
Enter.
5. You see an installation instruction screen. Follow the
instructions on the screen to install the utility on your
computer’s hard disk drive.
6. Once the utility is installed, log onto the directory you
specified for the utility. Then type
EPCALIB and press
Enter to start the program.
7. You see the
EPSON Print Head Alignment Utility main
screen. Make sure your printer is listed on the screen and
select
Next.
8. Follow the instructions on the utility screens to align your
print heads.
Selecting Character Tables
Most of the time you can select character tables using your
application software. If you can’t select them with your
software, follow the instructions here to select one of the
printer’s internal character tables.
You can select a character table using default-setting mode
(as described on page 5-3) or printer sofware commands (as
described on page 5-17). Each character table is identified by
the code shown beneath the sample, beginning on the next
page.
Note:
You can use a mouse
with the utility if you have
a DOS mouse driver
installed.
Note:
Some tables contain the
same characters for hex
codes 00 to 7F as the
PC437 table, so these
samples list only
characters for codes 80
to FF.
usedos.fm5 Page 8 Friday, May 9, 1997 1:54 PM
