Printing on Special Media
3-6
Printing on Single Sheets
You can print on single sheets of paper up to 17 inches wide
(432 mm) in your printer using the built-in sheet feeder or the
manual feeder.
You’ll probably use the built-in sheet feeder at the front of your
printer for the size paper you use most often, such as letter- or
legal-size sheets. Then you can use the manual feeder at the top
of the printer for loading individual, large format sheets or roll
paper using the optional Banner Paper Kit. (See page 3-22 for
more information on the Banner Paper Kit.)
Follow the instructions in the sections below to load single
sheets of paper from these feeders.
Loading Paper in the Built-in Sheet Feeder
You can load paper up to 17 inches wide (432 mm) in the
built-in sheet feeder, but do not load the stack above the arrow
mark on the right edge guide. Load legal-size or larger paper no
more than halfway to the arrow mark.
If you load paper more than 14.3 inches (364 mm) wide, load a
maximum of 30 sheets at a time, regardless of the paper type.
1. Turn on the printer, but don’t send a print job before you
load paper in the sheet feeder; always load paper first.
2. Set the paper release lever to the single sheet position (the
single sheet icon appears beneath the lever handle).
Note:
The maximum printable
width is 13.6 inches
(345 mm) on any size
paper.
single sheet icon
media.fm5 Page 6 Friday, May 9, 1997 1:48 PM
