Specifications
C-7
Safety Approvals
Safety standards UL 1950 with D3, CSA C22.2 950 with D3
EMC FCC part 15 subpart B class B
Interfaces
Parallel interface
Forward channel Data format: 8-bit parallel, IEEE-1284 compatibility mode
Synchronization:
STROBE pulse
Handshake timing:
BUSY and ACKNLG signals
Signal level: TTL compatible
Connector: 57-30360 Amphenol connector or equivalent
Reverse channel Transmission mode: IEEE-1284 Nibble mode
Adaptable connector: 57-30360 Amphenol Connector or equivalent
Synchronization: Refer to the IEEE-1284 specification
Handshaking: Refer to the IEEE-1284 specification
Signal level: IEEE-1284 Level 1 device
Data transmission timing: Refer to the IEEE-1284 specification
Serial interface
Standard: Based on RS-423
Synchronization: Synchronous
Bit rate: Maximum 1.8 Mbps
Handshaking: X-ON/X-OFF, DTR protocol
Word format:
Data bit: 8 bits
Parity bit: None
Start bit: 1 bit
Stop bit: 1 bit
Connector: 8-pin mini-circular connector
Recommended cable: Apple System Peripheral-8 cable (preferably
Belkin brand)
