Epson Stylus Color 670 Service Manual

EPSON Stylus Color 670 Revision A
Product Description Basic Specifications 12
1.2 Basic Specifications
1.2.1 Printing Specifications
PRINTING METHOD
o
On demand ink jet
NOZZLE CONFIGURATION
o
Black: monochrome 64 nozzles (32 x 2 rows staggered)
o Color: 32 nozzles per color row x 3 colors
(Cyan, Magenta, Yellow)
PRINTING DIRECTION
o Bi-direction with logic seeking
PRINTING SPEED AND PRINTABLE COLUMNS
CONTROL CODE
o ESC/P Raster command
o
EPSON Remote command
CHARACTER TABLES
o 2 international character sets
n
PC437 (US, Standard Europe)
n PC850 (Multilingual)
TYPEFACE
o Bit map LQ font
o
EPSON Courier 10 cpi
1.2.2 Paper Feeding
o Feeding method: Friction feed with ASF
o Paper path: Cut-sheet ASF (Top entry/Front exit)
o Feed speed: 8.47mm (1/3inch) feed:190ms
Continuous feed: 51mm/s
1.2.3 Input data buffer
o Input data buffer: 32KB
Table 1-1. Character Mode
Character pitch Printable columns LQ speed
10 cpi 80 200 CPS**
* This is not open to the user.
** This value is the speed of normal-dot printing.
Table 1-2. Printing Speed (Raster Graphics Mode)
Horizontal
Resolution
Printable Area Available Dot CR Speed
180 dpi 209.8mm (8.26 inch) 1488 508mm/s (20 IPS)
360 dpi 209.8mm (8.26 inch) 2976 508mm/s (20 IPS)
720 dpi 209.8mm (8.26 inch) 5952 508mm/s (20 IPS)
