Epson Stylus Color 670 Service Manual

EPSON Stylus COLOR 670 Revision A
Appendix Parts List 143
7.4 Parts List
Table 7-12. Stylus Color 670 Parts List
Part Number Description
100 HOUSING
101 COVER,PRINTER
102 PAPER SUPPORT;B
103 STACKER ASSY
104 PANEL ASSY
105 SHIEALDPLATE,PANEL
106 HOUSING,PANEL,LEFT
108 GROUNDING PLATE
109 COVER,SHIELD PLATE,M/B,RIGHT
111 COVER,CABLE;B
112 COVER,INLET,UPPER;B
113 COVER,INLET,LOWER;B
114 SHIALD,PLATE,M/B
115 LOGO PLATE
116 HOUSING,SUPPORT,RIGHT;B
117 HOUSING,SUPPORT,LEFT;B
119 FOOT
121 C.P.SCREW
122 C.B.S. SCREW
123 C.B.(O) SCREW,4X5,F/ZG
124 C.B.S. SCREW
125 C.B.P-TITE SCREW,3X8,F/ZN
126 C.B.P-TITE,3X10,F/ZN
128 MINI CLAMP
129 C.B.S.(P) SCREW
Q2 C.B.SCREW,2.6X8,F/ZN
Q3 C.B.SCREW,2.6X8,F/ZN
300 BOARD ASSY., POWER SUPPLY
330 WIRE HARNESS
400 POWER CABLE ASSY.
450 BOARD ASSY.,PANEL
500 PRINTER MECHANISM(ASP)M4L10-100
501 FRAME ASSY.,LEFT
502 MOTOR,ASSY,PF
503 SPUR GEAR,23.2
504 COMBINATIONGEAR,16,40.8
Table 7-12. Stylus Color 670 Parts List (continued)
Part Number Description
