Epson Stylus Color 670 Service Manual

EPSON Stylus COLOR 670 Revision A
Disassembly and Assembly Disassembly 71
4.2 Disassembly
The flowchart below shows step-by-step disassembly procedures. When
disassembling each unit, refer to the page number shown in the figure.
Figure 4-1. Flowchart
Printhead
Removal
Page 77
Pump/Cap Assy.
Removal
Page 80
CR Motor Assy.
Removal
Page 82
PF Motor Assy.
Removal
Page 83
CR Assy.
Removal
Page 93
PE Sensor Assy.
Removal
Page 95
PF Roller Assy.
Removal
Page 96
CR HP Sensor
Removal
Page 98
Housing
Removal
Page 72
Circuit Board Assy.
Removal
Page 73
Ink Absorber Tray Assy.
Removal
Page 76
Printer Mechanism
Disassembly
Page 77
Control Panel
Removal
Page 75
ASF Assy.
Removal
Page 85
LD Roller Assy.
Removal
Page 87
LD Roller Assy.
Disassembly
Page 92
