Epson Stylus Color 670 Service Manual

EPSON Stylus COLOR 670 Revision A
Appendix Parts List 146
587 C.B.S. SCREW
588 C.P.S-TITE(P4),3X6,F/ZN
589 LEAF SPRING
590 PLANE WASHER,2.6X0.5X8
591 CABLE,HEAD,A
592 CABLE,HEAD,B
615 PLATE,SLIDER,CLEANER
700 PRINT HEAD
701 FASTENER,HEAD
702 TORSION SPRING,49
703 C.B.P-TITE SCREW,3X6,F/ZN
705 HOLDER,CABLE
706 SPACER,CABLE HEAD
707 FRAME,ASF;B
708 HOPPER
709 EDGEGUIDE
710 CORK
711 SLIDER,EDGEGUIDE
712 COMPRESSION SPRING,3.23
Table 7-12. Stylus Color 670 Parts List (continued)
Part Number Description
713 PAD,BREAK,EDGE GUIDE
714 REINFORCEMENT PLATE,HOPPER
716 PAD ASSY.,RIGHT
717 LEVER,PAD,RELEASE,RIGHT
718 ROD SPRING,HOLDER,PAD
719 HOLDER,EDGEGUIDE,RIGHT
720 COMPRESSION SPRING,1.17
721 EXTENSION SPRING,0.62
722 LEVER,PAPERRETURN,RIGHT
723 EXTENSION SPRING,0.294
724 ROLLER,LD,SUPPORT
725 HOLDER,ROLLER,LD,SUPPORT,RIGHT
726 PAD ASSY.,LEFT
727 LEVER,PAD,RELEASE,LEFT
728 HOLDER,EDGEGUIDE,LEFT
729 LEVER,PAPERRETURN,LEFT
730 HOLDER, ROLLER,LD,SUPPORT,LEFT
731 ROLLER ASSY.,LD,LEFT
732 ROLLER ASSY.,LD,RIGHT
Table 7-12. Stylus Color 670 Parts List (continued)
Part Number Description
