T3-B T6-B Manipulator 7. Development PC Connection Port
T-B series Rev.1 91
7.2 Precaution
When connecting the development PC and the Manipulator, make sure of the following:
- Connect the development PC and the Manipulator with a 5 m or less USB cable.
Do not use the USB hub or extension cable.
- Make sure that no other devices except the development PC are used for development
PC connection port.
- Use a PC and USB cable that supports USB2.0 HighSpeed mode to operate in USB2.0
HighSpeed mode.
- Do not pull or bend the cable strongly.
- Do not allow unnecessary strain on the cable.
- When the development PC and the Manipulator are connected, do not insert or remove
other USB devices from the development PC. Connection with the Manipulator may
be lost.
7.3 Software Setup and Connection Check
Connection of the development PC and the Manipulator is indicated.
(1) Make sure that software EPSON RC+ 7.0 is installed to the Manipulator connected to
the development PC.
(Install the software when it is not installed. Refer to “EPSON RC+ 7.0 User’s Guide”.
(2) Connect the development PC and the Manipulator using a USB cable.
(3) Turn ON the Manipulator.
(4) Start EPSON RC+ 7.0.
(5) Select the EPSON RC+ 7.0 menu-[Setup]-[PC to Controller Communications] to
display the [PC to Controller Communications] dialog.
(6) Select “No.1 USB” and click the <Connect> button.
