T3-B T6-B Manipulator 3. Environments and Installation

64 T-B series Rev.1

(3) Hold the bottom of Arm #1 by hand to unscrew the anchor bolts.

Then, remove the Manipulator from the base table.

T3-B401S

Center of gravity

T6-B602S

Center of gravity
