Chapter 3 Handling
105
3
•DataMatrix(Rectangle)
Cell Size: Makes settings of the cell (module) size for DataMatrix.
Number of Vertical Cells: Specify the number of cells for DataMatrix in the vertical direction.
Number of Horizontal Cells: Specify the number of cells for DataMatrix in the horizontal direction.
[Minimize]: Optimize the minimum number of cells automatically.
[Specify the Size]: Change settings to the selected size.
❏ The following table shows the recommended value for the 2D symbol module.
•Recommended value for setting the barcode/2D symbol font (2D symbol of stack type)
(PDF417, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, GS1 DataBar
Expanded Stacked)
- : Not supported.
*
1 : Whether paper feed is performed during printing 2D symbol can be checked in [Display
Media Feed Position] - [Display Print Preview] in the Print Preview function. For this
function, see "Print Preview" on page 111.
*2: Specify when using PDF417.
Category
Graphic reso-
lutions
(Horizontal x
vertical) (dpi)
Print Status
(*1)
Adjust Bar
Width (*2)
Minimum Module
[by 360 dpi]
ANSI
Grade D
or
higher
ANSI
Grade C
or
higher
ANSI
Grade B
or
higher
Plain,
Plain label
360 x 360
No Paper
feed
3
6 dot - -
With Paper
feed
6 dot - -
Synthetic
label
Matte
Matte label
Glossy label
Wristband
360 x 360
No Paper
feed
4 dot - -
With Paper
feed
4 dot - (*2) -
720 x 360
No Paper
feed
4 dot - -
With Paper
feed
4 dot - (*2) -
