104
2
Make settings of the following items according to the selected [Type].
•PDF417
Module Width: Makes settings of the module width for PDF417.
Module Height: Makes settings of the module height for PDF417 by the ratio to the module
width.
Column: Input the number of columns for PDF417.
Step: Enter the number of steps for PDF417.
Truncation Symbol: Turn on this check box when making a symbol without the stop code.
Error Correction Level: Select an error correction level for PDF417. The data can be read even if the
part of the symbol is broken, and restoration ratio becomes higher for bigger
numbers.
•QRCode
Model: Select a QRCode model.
Module: Select the width of cell (module) for QRCode.
Version: Specify the version for QRCode. The number of characters that can be con-
verted into 2D symbols is different depending on the version of QRCode.
Error Correction Level: Select an error correction level for QRCode. The data can be read if the part
of the symbol is broken and restoration ratio becomes higher in the order of
level L, M, Q, H.
Characters: Enter the number of QRCode digits.
•MaxiCode
Mode: Select a MaxiCode mode. Turn on the check box of [Hexadecimal Entry
Mode] when selecting [Mode 2] or [Mode 3].
•GS1 DataBar
Module: Sets the module width for GS1 DataBar.
Num Of Chars: Sets the maximum width for GS1 DataBar.
•AztecCode
Type: Select a mode for AztecCode.
Number of Layers: Select the number of layers for AztecCode.
[Minimize]: Optimize the minimum number of layers automatically.
[Specify the Size]: Change the number of layers specified by the value in the
input box.
Cell Size: Sets the cell (module) size for AztecCode.
Error Correction Area: Specify the error correction area of AztecCode using of either the following.
The data can be read even if the part of the symbol is broken, and restoration
ratio becomes higher for bigger numbers.
[Default Value]: Default value is 23%+3 code words.
[Specify a Percentage]: Specify the error correction area with a percentage
value in the input box.
•DataMatrix
Cell Size: Makes settings of the cell (module) size for DataMatrix.
Number of Cells: Makes settings of the number of cells for DataMatrix.
[Minimize]: Optimize the minimum number of cells automatically.
[Specify the Size]: Change settings to the selected size.
