Chapter 6 Appendix
211
5
Media type Plain label / Matte label / Glossy label
Media source Roll paper
Backing paper width 30 to 112 mm {1.18 to 4.41"}
Label width 25.4 to 108 mm {1 to 4.25"}
Label length 8 to 1,117.6 mm {0.32 to 44"}
Gap between labels 3 to 6 mm {0.12 to 0.24"}
Left and right outer edges 2 mm 0.5 mm {0.079 0.02"}
Edge cutoff width 1.5 mm or more
Label edge R 1.5 mm {0.059"} or less
Width of a black mark 13 mm {0.51"} or more
Length of a black mark 4 mm {0.16"} or more
(with a width of at least 4 mm around)
Center of a black mark 8.5 mm 1 mm {0.33 0.039"}
Gaps between black marks 11 to 1,123.6 mm {0.43 to 44.24"}
Paper thickness Plain label / Matte label:
0.129 to 0.143 mm {0.005 to 0.006"}
Glossy label:
0.184 mm {0.007"}
Paper core Plain label:
outer diameter 44.1 mm {1.74"} or more
Matte label / Glossy label:
outer diameter 56.8 mm {2.24"} or more
External diameter Maximum 101.6 mm {4"}
Winding direction Printing face must be facing outside.
Form of perforated line Plain media : 1 mm {0.039"} uncut, 5 mm {0.2"} cut
Fine media : 1 mm {0.039"} uncut, 5 mm {0.2"} cut
PET film : 0.6 mm uncut, 8.4 mm cut
Do not use the paper with a hole or cutout.
For the black mark position of the die-cut label paper, match the label edge to the black
mark edge.
You can use paper with all fringes removed or paper with fringes on the left and right
removed.
