Epson TM-C3500 Series - Page 220

220
When "Borderless Printing" is enabled
Top, bottom, left, right margins: 0 mm (Typical value)
 If you enabled "Borderless Printing", printing is done with settings for no margins, but the
printing might protrude beyond the paper/label, depending on the actual print position
and the set position for the paper/label. To make sure printing does not protrude out,
ensure margins of 1.5 mm {0.06"} or more in the print data.
 Even if "Borderless Printing" is enabled, the maximum value for the print area width is
104 mm {4.09"}.
Paper width
Issuing pitch (Ph)
Auto-cut position
Auto-cut position
Paper feeding
direction
Print area
Interval of perforated lines (Pm)
Perforated line
Auto-cut position
Perforated line
Center of paper width
Print area width
Black mark
position
0.5 to 1.0 mm
15.0 mm or more (When auto cut is not per- formed: 8.0 mm or more)
