Chapter 6 Appendix
221
5
Full-page label / Roll paper
When "Borderless Printing" is disabled
Top, bottom, left, right margins: 1.5 mm (Typical value)
When the roll paper option is set to “Banner Mode,” a top margin is set only on the first
page of the print job, and not on the rest. A bottom margin is set on the last page of the print
job.
Paper width
1.5 mm
12.0 mm or more*1
15.0 mm or more*2
1.5 mm
1.5 mm
Auto-cut position
Auto-cut position
Paper feeding direction
Print area
2.0 mm
2.0 mm
1.5 mm
Label area
Center of paper width
Backing paper
Print area width
*1 When auto cut is not performed : 5.0 mm or more
*2 When auto cut is not performed : 8.0 mm or more
