Epson TM-C3500 Series - Page 222

222
When "Borderless Printing" is enabled
Top, bottom, left, right margins: 0 mm (Typical value)
 If you enabled "Borderless Printing", printing is done with settings for no margins, but the
printing might protrude beyond the paper/label, depending on the actual print position
and the set position for the paper/label. To make sure printing does not protrude out,
ensure margins of 1.5 mm {0.06"} or more in the print data.
 Even if "Borderless Printing" is enabled, the maximum value for the print area width is
104 mm {4.09"}.
Outer edge (Removed)
Paper width
15.0 mm or more
(When auto cut is not per-
formed: 8.0 mm or more)
Auto-cut position
Auto-cut position
Paper feeding direction
Print area
2.0 mm
2.0 mm
Label area
Center of paper width
Backing paper
Print area width
Outer edge (Removed)
