Starting on Windows
Note:
For Windows Server operating systems, make sure the Desktop Experience feature is installed.
❏ Windows 10/Windows Server 2016
Click the start button, and then select EPSON > Epson Scan 2.
❏ Windows 8.1/Windows 8/Windows Server 2012 R2/Windows Server 2012
Enter the application name in the search charm, and then select the displayed icon.
❏ Windows 7/Windows Vista/Windows XP/Windows Server 2008 R2/Windows Server 2008/Windows Server
2003 R2/Windows Server 2003
Click the start button, and then select All Programs or Programs > EPSON > Epson Scan 2.
Starting on Mac OS
Select Go > Applications > Epson
Soware
> Epson Scan 2.
Adding the Network Scanner
To use the network scanner, add the scanner by using the scanner driver "Epson Scan 2".
1.
Start Epson Scan 2.
❏ Windows 10/Windows Server 2016
Click the start button, and then select EPSON > Epson Scan 2.
❏ Windows 8.1/Windows 8/Windows Server 2012 R2/Windows Server 2012
Enter the application name in the search charm, and then select the displayed icon.
❏ Windows 7/Windows Vista/Windows XP/Windows Server 2008 R2/Windows Server 2008/Windows Server
2003 R2/Windows Server 2003
Click the start button, and then select All Programs or Programs > EPSON > Epson Scan 2.
❏ Mac OS
Select Go > Applications > Epson Soware > Epson Scan 2.
2.
On the Scanner Settings screen, click Add.
Note:
❏ If Add is grayed out, click Enable Editing.
❏ If the main screen of Epson Scan 2 is displayed, it has already been connected to the scanner. If you want to connect
to another network, select Scanner > Settings to open the Scanner Settings screen.
3.
Add the network scanner. Enter the following items, and then click Add.
❏ Model: Select the scanner you want to connect to.
❏ Name: Enter the scanner name. You can enter up to 32 characters.
❏ Search for Network: When the computer and the scanner are on the same network, the IP address is
displayed. If it is not displayed, click the
button. If the IP address is still not displayed, click Enter
address, and then enter the IP address directly.
4.
Select the scanner on the Scanner Settings screen, and then click OK.
Product Information > Software Information > Software for Scanning
372

Epson WorkForce Pro WF-C879R Specifications

General

Functions	Print, Copy, Scan, Fax
Duplex Printing	Yes
Scan Type	Flatbed, ADF
Scan Resolution	1200 x 2400 dpi
Fax Speed	33.6 Kbps
Fax Resolution	Up to 200 x 200 dpi
ADF Capacity	50 sheets
Maximum Paper Size	13" x 19"
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Print Technology	PrecisionCore
Print Resolution	4800 x 1200 dpi
Print Speed (Black)	24 ppm
Print Speed (Color)	24 ppm
Copy Speed	22 ppm (Color)
Copy Resolution	600 x 600 dpi
Mobile Printing	Apple AirPrint, Mopria Print Service
Display	4.3" color touchscreen
Monthly Duty Cycle	Up to 75, 000 pages
Ink Cartridge Configuration	4 individual ink packs (Black, Cyan, Magenta, Yellow)
