Pictograms and their Meanings
Pictograms are used in this Manual in order to support the understanding of the text and to
increase the efficiency of the practical work. In line with text no pictograms are used.
Menu
-menu is written
next to the pictogram in a hierarchical form.
Example:
System
Calibration
XY gantry
Soft Key
Meaning of pictogram: "click the soft key ...". The corresponding soft key is written next to the
pictogram in bold italic font.
Example:
Calibrate all
Tool
Meaning of pictogram: a tool is required to carry out a step in a procedure. The pictogram is placed
next to the corresponding instruction.
Example:
Tighten the fixation screw.
Check
Meaning of pictogram: a selection has to be done (check boxes). The pictogram is placed next to
the corresponding instruction.
Example:
Setup check
Hint / Notification
Meaning of pictogram: a pop up window giving a hint or a warning. The text of the pop up window
is written next to the pictogram in a non proportional font.
Example:
Make sure that all boards are removed before continuing calibration
