Corrective Maintenance
5-6 © Essemtec AG Fox Maintenance
0000074/05
/ March 31, 2017
Adjust circlip pliers (SP/TOOL-26)
Note:
The circlip pliers is not scope of the
machine delivery.
The delivered circlip pliers may vary from
the illustration.
Adjust the pliers to a width of 2.8 mm.
A wider opening can bend the circlip out of
shape. The replacement of the circlip cannot be
done in the field.
Remove Head Covers (if not already removed)
From the front side of the machine, loosen and
remove the 2 fixing screws of the cover.
Remove the cover.
