Calibration of the Machine
3-8 © Essemtec AG Fox Maintenance
0000074/05
/ March 31, 2017
Place the PCB table on the distance bolts and
press it to the front.
Screw in and tighten the four fixing screws.
Finalize Mapping
Continue with the calibration or at least calibrate the PCB Handling, following the instructions
given by the software.
At least go to menu System - Calibration - PCB Handling and press Calibrate all.
