Clean and lubricate guide shaft.
Using a soft and lint-free cloth, lightly dampened
with IPA Isopropyl alcohol, wipe all guide shafts
of the head as indicated in the picture.
Lubricate the guide shafts slightly with Essemtec
P&P Head Grease (SP26/HG01) by means of a
brush (anytime keep the brush clean, free of
dust and metal powders). Do not apply too
much grease. Move manually the the Z-axis up
and down to apply evenly the grease. Wipe off
any excess.
Clean and lubricate ball cage.
The ball cage cannot be removed for cleaning
and lubricating. Pull down the element and the
ball cage as far as possible. Use a soft and lint-
free cloth and wipe off the dirty grease outside
of the cage. Turn the element during cleaning.
Afterwards lightly dampen a soft and lint-free
cloth with IPA Isopropyl alcohol (only
fatdissolving liquids) and wipe the ball cage
outside as long as it is clean and free of grease.
Wipe also the shaft.
Afterwards lubricate the ball cage slightly with
Essemtec P&P Head Grease (SP26/HG01) by
means of a brush. Do not apply too much
grease, just a very thin film. Move manually the
the Z-axis up and down to apply evenly the
grease. Wipe off any excess.
