Preventive Maintenance
4-56 © Essemtec AG Fox Maintenance
0000074/05
/ March 31, 2017
No blow off:
Remove the vacuum hose on the valve, shown
on picture.
Position the reject bin underneath the ZT
elements for the collection of the rinsing liquid
(1).
By means of the squeeze bottle, syringe or
similar dosing unit, press the Isopropanol or
methylated spirit through the first passage to
rinse it (2). Vacuum passage with blow off (3).
