Essemtec Fox - Page 93

Preventive Maintenance
Fox Maintenance © Essemtec AG 4-57
0000074/05
/ March 31, 2017
Clean the spindle tip by means of the conical
brush for spindle cleaning out of the
maintenance kit SP26/MAIN02 (see picture).
By means of the squeeze bottle, syringe or
similar dosing unit, press the Isopropanol or
methylated spirit through the first passage
again.
Afterwards plug in the vacuum hose on the first
valve for blowing out the cleaning liquid and
drying the passage.
Repeat above steps for all vacuum hoses, one by one.
Switch off the air blow.
After rinsing the last passage, wait 5 minutes
before switch off the air blow.
System
Adjustments
Air
uncheck to switch off the air blow on all ZT
elements.
Reattach the Covers
Carefully place the top head cover on the correct
position.
Screw in the three fixing screws and tighten
them (see picture).
