4.4.2.2.13. Selecting the Sine Wave Level
This menu item is used to select the output amplitude of the sine wave sync
formats. This affects the subcarrier modes and the 5MHz/10MHz modes.
When the Sine wave level is set to +/-1 volts, then the output will be 2 volts
peak-to-peak in amplitude (unterminated).
When the Sine wave level is set to +/-2 volts, then the output will be 4 volts
peak-to-peak in amplitude (unterminated).
4.4.2.2.14. Selecting the Wordclock Level
This menu item allows the user to select the wordclock output level for the
wordclock sync output mode. This affects only the wordclock output mode.
When 5V CMOS
is selected, the wordclock output amplitude will be 0V
during channel 2 (right channel) and will be 5V during channel 1 (left
channel). This assumes an unterminated output.
When +/-1 Volts is selected, the wordclock output will be -1V during channel
2 (right) and +1V during channel 1 (left). This assumes an unterminated
The output impedance of the sync outputs is 75Ω. The output amplitudes will
drop by half when loaded with a 75Ω termination.
