Model 5601MSC
Model 5601MSC Master SPG/Master Clock System
MASTER CLOCK Revision 2.2 Page - 127
4.4.6.1. Setting the Analog Audio Tone Frequency
OUTPUT
The Left frequency and Right frequency menu items are used to select the
frequency of the tone that will be output onto the analog audio channels.
These controls are only valid when the Audio Mode is set to Steady tones.
Move the selection cursor (>) to t
he desired frequency and press the
SELECT button to apply it to the output.
Analog Audio
Left frequency
Right frequency
20 Hz
60 Hz
100 Hz
200 Hz
400 Hz
800 kHz
1.0 kHz
1.6 kHz
2.0 kHz
3.2 kHz
4.0 kHz
5.0 kHz
6.4 kHz
8.0 kHz
10 kHz
12 kHz
4.4.6.2. Configuring the Analog Audio Tone Level
OUTPUT
There are two menu items used to set the volume of the analog audio
outputs. When either the Left level or Right level menu items are selected,
the right LCD panel will display an audio level adjustment screen. The active
adjustment will be highlighted while the other adjustment will be shown in
dark text. Rotate the control knob or press the  and  buttons to change
the current audio level. Turning the control knob while pressing it in allows
making quicker adjustments in larger steps.
The audio level range is from +10.0 dBu down to –30.0 dBu. The lowest
setting is Mute
, which effectively disables the analog audio channel. The
adjustments are done in steps of 0.1 dBu (decibels unloaded).
Caution: These
menu items are live controls. Any changes to the audio
levels will immediately affect the analog audio outputs.
Analog Audio
Left level
Right level
Audio Level
Left 10.0dBu
Right 0.0dBu
4.4.6.3. Setting the Analog Audio Generation Mode
OUTPUT
There are two output modes for the Analog Audio outputs.
Select Steady tones to generate continuous audio tones as defined by the
Left Frequency and Right Frequency controls. These tones will be very pure
with a low total harmonic distortion.
Select Timed toned for event driven tone generation. There are a total of ten
audio events that can be configured to activate at different times for
adjustable durations. These tones can be programmed to go off at a certain
time of the day, or periodically every hour or every minute.
Analog Audio
Audio Mode
Steady tones
Timed tones
