ATG 1
generator output. There are different test patterns available for the PAL-B
and NTSC-M image formats.
Caution: This menu item is a live control. Changes made by pressing the
 and  buttons or rotating the control knob will immediately affect the
picture output of the analog test generator.
See section 4.4.5
for a complete list of test signa
ls included with the
5601MSC firmware and those that can be added by loading a
CompactFlash card and inserting it into the unit.
Signal
BLACK
GREY
WHITE
FIELDID (B=1,W=2)
10 Y STEP
Y RAMP
SHALLOW Y RAMP
MODULATED RAMP
CCIR 17
CCIR 18
75% COLOR BARS
100% COLOR BARS
SMPTE BARS
NTC7 COMPOSITE
NTC7 COMBINATION
FCC CCOMPOSITE
FCC MULTIBURST
60% EXTENDED MB
Y MULTIPULSE
2T PULSE & BAR
SIN(X)/X
COMPOSITE SIGNAL
more ...
4.4.4.2. Selecting the Standard of the Analog Video Test Generator
OUTPUT
This menu item sets the output format of the analog video test generator.
ATG 1
Image Format
525 NTSC M
625 PAL B
