Model 5601MSC
Model 5601MSC Master SPG/Master Clock System
MASTER CLOCK Revision 2.2 Page - 153
4.5.14.3. Setting the PTP DSCP value
GENERAL
This menu item is used to set the PTP Differentiated Services Code Point
(DSCP) value. Note that only 16, 18, 20, 24, 32, 24, 28, 40, 48, 52, 54, and
56 should be used. Other values are available for user defined systems.
The range is 0 to 63.
PTP Master
DSCP
dscp 56
4.5.14.4. Setting the Sync Rate
GENERAL
This menu item sets the rate at which to send master broadcast packets.
If Master mode is set to Annex J, the range is 1 per 2 seconds to 2 per
second. If Master mode is set to SMPTE 2059, the range is 2 per second
to 128 per second.
PTP Master
Sync Rate
1 per 2 sec
1 per sec
2 per sec
4 per sec
8 per sec
16 per sec
32 per sec
64 per sec
128 per sec
4.5.14.5. Setting the Announce Rate
GENERAL
This menu item is used to set the rate at which to send master
announcement packets. If Master mode is set to Annex J, the range is 1
per 16 seconds to 1 per 2 seconds. If Master mode is set to SMPTE 2059,
the range is 1 per 2 seconds to 8 per second.
PTP Master
Announce Rate
1 per 16 secs
1 per 8 secs
1 per 4 secs
1 per 2 secs
1 per sec
4.5.14.6. Setting the Timeout Value
GENERAL
This menu item sets the timeout value for received announcement packets.
It is in units of time of sent announce packets. Its range is 2 to 10.
PTP Master
Timeout
3 announces
4.5.14.7. PTP Priority 1
GENERAL
This menu item sets the priority 1 value for the BMC. Its range is 0 to 255.
PTP Master
PTP Priority 1
priority 1 128
