Model 5601MSC
Model 5601MSC Master SPG/Master Clock System
MASTER CLOCK Revision 2.2 Page - 111
4.4.3. Configuring the SDI Video Test Generator Outputs (SDTG, HDTG, 3GTG options)
There are four menus to control each of the SDI video test generators. These menus are all identical to
each other and for the sake of simplicity, only the SDI TG 1 menu will be described in the manual.
4.4.3.1. Selecting the SDI Test Generator Test Pattern
The Signal menu item is used to select the test pattern for the SDI test
generator output. The test patterns available will depend on the link
format selected and also on the current image format.
Caution: This menu item is a live control. Changes made by pressing
the and buttons or rotating the control knob will immediately affect
the picture output of the SDI test generator.
See section 4.4.5
for a complete list of test signals included with the
5601MSC firmware and those that can be added by loading a
CompactFlash card and inserting it into the unit.
WHITE
FIELDID(B=1,W=2)
FRAME IDENT
100% COLOR BARS
75% COLOR BARS
RP219 COLORBARS
VALID RAMP
100%WHITE WINDOW
50% WHITE WINDOW
20% WHITE WINDOW
SDI CHECKFIELD
GREY (QUIET)
GREY (ACTIVE)
10 FRAME SEQUNCE
BOUNCING BOX
4.4.3.2. Selecting the Interface Type of the SDI Video Test Generator
The Interface menu item is located in the Format sub-menu and is used to
select the physical SDI interface type for the SDI test generator. Each SDI
test generator has two BNC outputs and this menu item controls what will
be present on the BNCs. Depending on the options that are installed on
the 5601MSC some of the menu items may not be available.
Select Single Link HD for a 1.48Gb/s (SMPTE ST 292-1) interface speed
for 1080i/1080p (SMPTE ST 274), 720p (SMPTE ST 296), and 2k DCDM
(SMPTE ST 428) image formats. Both BNCs will contain the same video.
Select 3G Level A for a 2.97Gb/s (SMPTE ST
direct image format mapping (SMPTE ST 425-1 Level A).
Select 3G Level B for a 2.97Gb/s (SMPTE ST
Dual Link format mapping (SMPTE ST 372).
Select Dual Link HD for a 1.48Gb/s (SMPTE ST 292-1) interface speed for
dual-link image formats (SMPTE ST 372). In this format the BNC labelled
(A) will be Link A and the BNC labelled (B) will be Link B.
Select Standard Def for a 270Mb/s (SMPTE ST
259) interface speed for
525i/59.94 (SMPTE 125M) and 625i/50 (ITU-R BT.601) image formats.
3G Level A
3G Level B
Dual Link HD
