evertz 5601MSC - Table 4-8: Vistalink

Model 5601MSC
Model 5601MSC Master SPG/Master Clock System
Page - 164 Revision 2.2 MASTER CLOCK
Tab Name
Description
Status
Displays the status of the reference, GPI, and syncro inputs
Menu Access
Configures front panel menu restrictions
Reference Control
Contains the frequency and time reference settings
LTC Outputs
Settings for LTC/IRIG outputs (LTC1 and LTC2)
SYNC1 & SYNC2
Contains all controls for the Sync1 and Sync2 outputs
SYNC3 & SYNC4
Contains all controls for the Sync1 and Sync2 outputs
SYNC5 & SYNC6
Contains all controls for the Sync1 and Sync2 outputs
10MHZ & WORDCLOCK
Contains all controls for the 10MHz and Wordclock outputs
Global
Global phasing/pedestal controls and system presets
Analog Audio
Controls for configuring the analog audio outputs
AES1, AES2 & DARS
Controls for configuring the digital audio outputs
General
Settings involving DST, Modem, GPIO, and passwords
NTP General
Configures the NTP restrictions
Notify
Configures and displays the status of the traps/alarms
SDI TG1 Control
Output format, phasing, and message controls for SDI TG1
SDI TG1 Audio
Embedded audio configuration for SDI TG1
SDI TG1 Picture
Test pattern selection for SDI TG1
SDI TG2 Control
Output format, phasing, and message controls for SDI TG2
SDI TG2 Audio
Embedded audio configuration for SDI TG2
SDI TG2 Picture
Test pattern selection for SDI TG2
SDI TG3 Control
Output format, phasing, and message controls for SDI TG3
SDI TG3 Audio
Embedded audio configuration for SDI TG3
SDI TG3 Picture
Test pattern selection for SDI TG3
SDI TG4 Control
Output format, phasing, and message controls for SDI TG4
SDI TG4 Audio
Embedded audio configuration for SDI TG4
SDI TG4 Picture
Test pattern selection for SDI TG4
Analog TG1 Control
Video format, phasing, and message controls for ATG1
Analog TG1 Picture
Test pattern selection for the ATG1 output
Analog TG2 Control
Video format, and phasing controls for ATG2
Analog TG2 Picture
Test pattern selection for the ATG2 output
Table 4-8: VistaLINK
®
Control Screens
Changing a setting is accomplished by clicking on the desired item and selecting a different setting.
Press the green Apply button at the top to send the changes to the 5601MSC. For making live changes,
Dynamic Apply can be turned on by clicking on the red Apply button. When Dynamic Apply is turned on,
any change made will be immediately sent to the 5601MSC. This is useful when adjusting phase, for
example.
Once the desired changes have been made, press the refresh button to refresh the configuration
screen by pulling the settings from the 5601MSC.
