Model 5601MSC
Model 5601MSC Master SPG/Master Clock System
MASTER CLOCK Revision 2.2 Page - 145
4.5.10.1. Setting the DST Date Entry Mode
GENERAL
This menu item allows the user to set the method of entering the DST
information in the DST registers.
Select day/week/month
to enter the DST information in the following
format:
Sunday of week 1 of month 4 (e.g. Sunday of first week of April)
Select day of month to enter the DST information in the following format:
Day 1 of month 4 (e.g. First day of April)
DST rules
DST mode
day/week/month
day of month
4.5.10.2. Setting the DST Start Hour
GENERAL
This menu item allows the user to set the hour of the day when DST
begins. Use the control knob to change the start hour for DST in 24 hour
time.
DST rules
Start Hour
New value
DST starts 0200
Set value
DST starts 0200
4.5.10.3. Setting the DST Start Day
GENERAL
When the DST date mode menu is set to day/week/month this menu item
allows the user to set the day of the week when DST begins. Use the
control knob to change the start day for DST.
When the DST date mode menu is set to DST Start Day this menu item
allows the user to set day of the week when DST begins.
DST rules
DST start day
Day1 – Day31
Sunday
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
4.5.10.4. Setting the DST Start Week
GENERAL
When the DST date mode menu is set to day/week/month this menu item
allows the user to set the week of the month when DST begins. Set the
value to last wk when DST starts on the fourth or fifth week of the month
depending on the year.
When the DST date mode menu is set to day of month this menu item is
not used, and will display “Not in Week Mode”.
DST rules
DST start week
First week
Second week
Third week
Fourth week
Last week
