4.4.3.7. Configuring the On-Screen Message for the SDI Test Generator Outputs
It is possible to overlay a user-defined text message onto the outputs of the SDI test generators. There
are six menu items used to control the message displayed and are described below.
4.4.3.7.1. Enabling the On-Screen Message for the SDI Test Generator
OUTPUT
This menu item is used to enable the on-screen message and to select
how many lines will be overlaid onto the SDI test generator output.
When set to Message off, the text message will not be visible.
When set to Message 1 line, the first line of text will be overlaid onto the
SDI test generator video output.
When set to Message 2 lines, there will be two lines of text overlaid onto
the SDI test generator video output.
SDI TG 1
Message Ctl
Message off
Message 1 line
Message 2 lines
4.4.3.7.2. Setting the On-Screen Message Position for the SDI Test Generator
OUTPUT
There are two menu items used to control the position of the test
message on the SDI test generator video output. When either menu item
is selected, the right LCD display will show a message position screen
where the active adjustment will be highlighted and the other adjustment
will be in dark text.
The H position menu item is used to control the horizontal position of the
text message.
The V position
menu item is used to control the vertical position of the
text message.
SDI TG 1
H Position
V Position
Message position
Vert. hor.
2 1
4.4.3.7.3. Entering User-Defined Text for the On-Screen Message
OUTPUT
There are two lines of user-defined text that can be entered using the
Message 1 and Message 2 menu items. When entering text, use the 
and  buttons or turn the control knob to set each character. Press the
SELECT button to advance to the next character. Turn the control knob
all the way counter-clock wise to get to the space character. There is a
maximum of 16 characters. When finished press the SELECT button.
The Message 1 menu item allows entry of text for the first message line.
The Message 2 menu item allows entry of text for the second line.
SDI TG 1
Message 1
EVERTZ 5601MSC
Message 2
Master Sync
