4.4.3.6.2. Selecting the Audio Tone for an SDI Embedded Audio Channel
There are 4 identical menu items to select the tone frequency for each of the audio channels in the
group. For the sake of simplicity only the menu item for channel 1 is described in the manual.
OUTPUT
The Ch1 Frequency menu item is used to select the frequency of the
tone that will be embedded into audio channel 1.
Selecting one of these signals will set the frequency of the tone that is
embedded into this channel.
SDI TG 1
Audio Group 1
Ch 1 frequency
Ch 2 frequency
Ch 3 frequency
Ch 4 frequency
20 Hz
60 Hz
100 Hz
200 Hz
400 Hz
800 Hz
1.0 kHz
1.6 kHz
2.0 kHz
3.2 kHz
4.0 kHz
5.0 kHz
6.4 kHz
8.0 kHz
10 kHz
12 kHz
4.4.3.6.3. Setting the Audio Level for an SDI Embedded Audio Channel
There are 4 identical menu items to set the audio level for each of the audio channels in the group. For
the sake of simplicity only the menu item for channel 1 is described in the manual.
OUTPUT
The Ch 1 level menu item is used to set the audio level of the tone that
was selected for channel 1 of the audio group.
The audio level is set in units of dBFS (dB Full-Scale) and is adjustable
in increments of 1 from 0 dBFS to –60 dBFS.
Select mute to completely mute the audio channel.
SDI TG 1
Audio Group 1
Ch 1 level
mute
0 dBFS
