Model 5601MSC
Model 5601MSC Master SPG/Master Clock System
Page - 124 Revision 2.2 MASTER CLOCK
4.4.4.4.12. Selecting the Analog Video Test Generator Burn In Timecode Time Zone Offset
This menu item allows the user to set a time zone offset between the
system time and the analog video test generator burn in time. The time zone
offset value is set in 30-
minute increments. The system time should be
running at UTC. This time zone
offset will be added to the system time
along with the Daylight Saving Time correction (see section 4.4.2.2.10) and
the analog video test generator b
urn in time frame offset (see section
4.4.2.2.8) to obtain the final SDI burn in time.
Use the and
buttons or turn the control knob to move the cursor to
select the desired time zone offset. Press the SELECT button to choose the
indicated value. It will then become highlighted to show it is the active value.
to
4.4.4.4.13. Enabling Daylight Saving Time for the Analog Video Test Generator Burn in Clock
This menu item allows the user to control whether the Daylight Saving Time
(DST) adjustment will be applied to the analog video test generator burn in.
When set to Off
, Daylight Saving Time compensation will not be applied to
the SDI burn in time.
When set to On the rules set by the DST rules menu in the GENERAL root
menu will be used to adjust the analog video test generator
burn in time
(see section 4.5.9.5).
4.4.4.5. Setting the Analog Test Generator Syncro Mode
This menu item controls the behaviour of the analog TG when the unit is
in syncro mode. If syncro is not enabled this menu item is ignored.
Select Include syncro to include the analog TG in the synchronization of
menu items between the master and slave units.
Select Exclude syncro to exclude the analog TG from synchronizing its
settings with the master or slave unit. This allows the TG to be modified
freely on the slave unit to different settings than the master.
Include syncro
Exclude syncro
